| Vehicle category | N2 |
| Wheel arrangement / drive wheel | 4×2 / rear |
| Gross vehicle mass, kg | 8 000 |
| Tank capacity, l | 800 |
| Garbage tank capacity, m³ | 4 |
| Suction power, kg | 5 |
| Fuel tank capacity, l | 100 |
| Fuel type | diesel |
| Seating capacity | |
|---|---|
| Driver | 1 |
| Crew | 1 |
| Chassis dimensions mm | |
| Length | 6 730 |
| Width | 2 210 |
| Height | 3 098 |
| Wheelbase | 3 815 ± 20 |
| Engine | |
| Model | ISUZU 4HG1 turbocharging provided four-stroke diesel |
| Number and arrangement of cylinders | 4 in a row |
| Compressive ratio | 19 : 1 |
| Displacement, sm³ | 4 554 |
| Maximum power kW/HP (RPM) | 89/121 (3200) |
| Maximum torque, Nm (min) | 304 (1800) |
| Location of engine | front longitudinal |
| Brake system | |
| Working | cylinder type with hydraulic 2 contours based drive with a hydraulic-assisted independent distribution by the axes |
| Parking | mechanical, cylinder type output spindle of gearbox driven |
| Spare | one of the contours of a working braking system |
| Auxiliary | engine retarder |
| Availability of an Anti-lock Braking System (ABS) | yes |
| Tires | |
| Brand | 8.25-16-14PR |
| Transmission | |
| Brand | MYY5T |
| Number of gears | 5 |
| Ratio of transmission | |
| I | 5,315 |
| II | 3,053 |
| III | 1,655 |
| IV | 1,000 |
| V | 0,721 |
| Back running | 5,068 |
