| Vehicle category | N2 |
| Wheel arrangement / drive wheel | 4×2 / rear |
| Gross vehicle mass, kg | 5 200 |
| Payload, kg | 2 430 |
| Fuel tank capacity, l | 75 |
| Fuel type | diesel |
| Seating capacity | |
|---|---|
| Driver | 1 |
| Crew | 1 |
| Body | |
| Length | 3055 |
| Width | 1960 |
| Height | 1780 |
| Chassis dimensions mm | |
| Length | 4 730 ± 100 |
| Width | 1 975 ± 100 |
| Height | 2 750 ± 100 |
| Wheelbase | 2 460 ± 30 |
| Engine | |
| Model | ISUZU 4JB1 four-stroke diesel |
| Number and arrangement of cylinders | 4 in a row |
| Compressive ratio | 17,8 : 1 |
| Displacement, sm³ | 2 771 |
| Maximum power kW/HP (RPM) | 59/80 (3600) |
| Maximum torque, Nm (min) | 175 (2000) |
| Location of engine | front longitudinal |
| Brake system | |
| Working | cylinder type with hydraulic 2 contours based drive with a vacuum-assisted independent distribution by the axes |
| Parking | mechanical, cylinder type output spindle of gearbox driven |
| Spare | one of the contours of a working braking system |
| Auxiliary | engine retarder |
| Availability of an Anti-lock Braking System (ABS) | no |
| Tires | |
| Brand | 7.00-16-10 7.00R16-10 |
| Transmission | |
| Brand | MSB5M |
| Number of gears | 5 |
| Ratio of transmission | |
| I | 5,594 |
| II | 2,914 |
| III | 1,660 |
| IV | 1,000 |
| V | 0,794 |
| Back running | 5,334 |
