| Vehicle category | M3 City (low-floor) bus |
| Number of doors | two service doors at the right side of the body |
| Passenger capacity, pers. | 56 + 1 |
| Gross vehicle mass, kg | 10 200 |
| Maximum bus speed, km/h | 80 |
| Fuel tank capacity, l | 140 |
| Fuel type | diesel |
| Base equipment: | – Air suspension |
| – Stencil destination indicator | |
| – The driver’s seat with mechanical cushioning system | |
| – Heated rear view mirror | |
| – The side windows on glue junction | |
| – Vent windows on the side windows | |
| Optional equipment: | – Spare wheel with a set of tools |
| – Electronic suspension control, leaning (ECAS) | |
| – Electronic programmable destination indicator | |
| – Voice connectivity with passenger compartment(microphone) | |
| – The driver’s seat on pneumatic suspension | |
| – Rampant for disabled persons | |
| – Remote setting-up for rear view mirrors (joystick) |
| Seating capacity | |
|---|---|
| Passengers | 25 |
| Bus crew | 1 |
| Chassis dimensions mm | |
| Length | 8 065 ± 50 |
| Width | 2 470 ± 30 |
| Height | 2 750 ± 50 |
| Wheelbase | 4 540 ± 30 |
| Engine | |
| Model | Cummins 4ISBe4 185B / ISUZU 4HK1-TCC |
| Location of engine | transversal in the rear overhang |
| Number and arrangement of cylinders | 4 in a row |
| Compressive ratio | 17,3 : 1 / 17.5 : 1 |
| Displacement, sm³ | 4 500 / 5 193 |
| Maximum power kW/HP (RPM) | 136/185 (2500) / 140/190 (2600) |
| Maximum torque, Nm (min) | 686 (1400) / 510 (1600) |
| Emission standard | Euro-3 / Euro-4 |
| Brake system | |
| Working | circular, pneumatic 2-contours based with independent distribution by axes |
| Parking | diaphragm spring brake cylinder rear wheels driven |
| Spare | one of the contours of a working braking system |
| Auxiliary | engine retarder |
| Tires | |
| Brand | 225/75 R 17.5 |
| Transmission | |
| Brand | Allison 2100 |
| Number of gears | 5 |
| Ratio of transmission | |
| I | 3,10 |
| II | 1,81 |
| III | 1,41 |
| IV | 1,00 |
| V | 0,71 |
| Back running | 4,49 |
| Final drive (brand, type) | Raba, conical gear |
