| Vehicle category | M3 |
| Number of doors | two service doors at the right side of the body, driver’s door at the left side |
| Passenger capacity, pers. | 38 |
| Gross vehicle mass, kg | 7 000 |
| Maximum bus speed, km/h | 90 |
| Fuel tank capacity, l | 100 |
| Fuel type | diesel |
| Seating capacity | |
|---|---|
| Passengers | 16 |
| Bus crew | 2 |
| Chassis dimensions mm | |
| Length | 6 920 ± 30 |
| Width | 2 240 ± 10 |
| Height | 2 880 ± 50 |
| Wheelbase | 3 815 ± 15 |
| Engine | |
| Model | ISUZU 4HF1 four-stroke diesel |
| Number and arrangement of cylinders | 4 in a row |
| Compressive ratio | 19 : 1 |
| Displacement, sm³ | 4 334 |
| Maximum power kW/HP (RPM) | 78/104 (3200) |
| Maximum torque, Nm (min) | 268 (1800) |
| Brake system | |
| Working | cylinder type with hydraulic 2 contours based drive with a vacuum-assisted independent distribution by the axes |
| Parking | mechanical, cylinder type output spindle of gearbox driven |
| Spare | one of the contours of a working braking system |
| Auxiliary | engine retarder |
| Availability of an Anti-lock Braking System (ABS) | no |
| Tires | |
| Brand | 7,50х16 C12PR / 7,50х16 C14PR / 8,5 R 17,5 Tubeless |
| Transmission | |
| Brand | MYY5T |
| Number of gears | 5 |
| Ratio of transmission | |
| I | 5,315 |
| II | 3,053 |
| III | 1,655 |
| IV | 1,000 |
| V | 0,721 |
| Back running | 5,068 |
