| Vehicle category | N3 |
| Wheel arrangement / drive wheel | 4×2 / rear |
| Gross vehicle mass, kg | 15 100 |
| Payload, kg | 8 000 |
| Body volume, m³ | 5.28 |
| Fuel tank capacity, l | 200 |
| Fuel type | diesel |
| Seating capacity | |
|---|---|
| Driver | 1 |
| Crew | 2 |
| Sleeper | 1 |
| Body | |
| Length | 4 000 |
| Width | 2 200 |
| Height | 600 |
| Chassis dimensions mm | |
| Length | 6 500 ± 100 |
| Width | 2 490 ± 70 |
| Height | 2 950 ± 100 |
| Wheelbase | 3 900 ± 20 |
| Engine | |
| Model | ISUZU 6HH1-S four-stroke diesel |
| Number and arrangement of cylinders | 6 in a row |
| Compressive ratio | 18.5 : 1 |
| Displacement, sm³ | 8 226 |
| Maximum power kW/HP (RPM) | 147/200 (2850) |
| Maximum torque, Nm (min) | 500 (1700) |
| Location of engine | front longitudinal |
| Brake system | |
| Working | pneumatic 2-contours based, braking mechanism of all wheels is of cylindrical type |
| Parking | rear wheel drive |
| Spare | one of the contours of a working braking system |
| Auxiliary | engine retarder |
| Availability of an Anti-lock Braking System (ABS) | no |
| Tires | |
| Brand | 11R22,5 148/145L |
| Transmission | |
| Brand | MLD6A |
| Number of gears | 6 |
| Ratio of transmission | |
| I | 8,761 |
| II | 5,533 |
| III | 3,569 |
| IV | 2,389 |
| V | 1,533 |
| VI | 1,000 |
| Back running | 8,896 |
